LOCTITE C502 no clean/clear residue cored Solder Wire made of lead-free alloy.

Loctite 502 is designed for users who require a low-halide formulation. The remaining products in the range contain differing halide levels to optimise soldering power. Henkel Loctite 400, 502 and 511 cored wire is manufactured with a range of flux contents. Although users will normally be using products with a nominal flux content of 3%, the superior performance of these products may allow a lower flux content to be specified e.g. 2.2%. This will further improve residue appearance by reducing the quantity


Qualities and Characteristics

  • Low halide version
  • Fast soldering, range of activities to suit all applications
  • Good spread on copper, brass and nickel
  • Clear residues
  • Heat stable, low spitting

Technical Attributes

Flux Type No Clean and Rosin Flux
Melting Temperature 227°C

Physical Attributes

Solder Alloy 99.3, 0.7 Sn, Cu, Cu
External Diameter (Metric) 0.7mm
External Diameter (Imperial) 0.028"
Weight (Metric) 500g
Weight (Imperial) 1.102lb
Write Your Own Review
You're reviewing:LOCTITE 99C C502 5C 0.7MM 0.25KG
Your Rating
£25.00 (£30.00 inc VAT)

LOCTITE Multicore 99C CRYSTAL 502 0.7MM WIRE X 250GM
