This support is perfectly adapted to any type of small PCB by means of its many adjustable elements.It allows you to properly position PCBs of the same batch so as to always heat the same area. It is ideal for repetitive soldering jobs which means saving time and optimizing workflow.PHN-SA incorporates several slots for precise alignment to PHNE Nano Preheater Set.The user can modify the PCB clearance (28, 50 or 70 mm / 1.1, 2 or 2.8 in) according to their working needs.It is also possible to use the 4 black-rubber caps for reworking larger PCBs.


Qualities and Characteristics

  • Can adapt to any small PCB due to its adjustable elements
  • Ability to properly posistion PCBs
  • Precise allignment
  • Also possible to rework larger PCBs due to its 4 black-rubber caps

Product Contains

  • 1 PHN-SA Nano PCB Support

Technical Attributes

PCB Support 238 x 237 x 96 mm / 1.90 kg
Low Position 238 x 237 x 75 mm
High Position 238 x 237 x 96 mm

ESD/EOS

ESD Safe Connector
