This Solder Feeder allows you to feed solder wire automatically from any position.You can easily configure parameters such as dispensed wire speed and length. You can also monitor the solder consumption thanks to integrated counters.


Qualities and Characteristics

  • Three working modes
  • Solder Wire Perforation
  • The SF includes the ergonomic SF280-A Solder Feed Handle and the Ø 1 mm GSF10V Guide Set. Compatible Guide Sets are also without Solder Wire Perforation available.
  • SF-210VB 230V & Ø1mm


Product Contains

  • 1 SF-210VB 230V & Ø1mm Automatic Solder Feeder
  • 1 SF280-A Solder Feed Handle
  • 1 GSF10V Guide Set for SF280-A

Technical Attributes

Maximum Speed 120 mm/s

Practical Attributes

Communication Connectors USB-B peripherals RJ12 for RS-232 connection

Solder Compatibility

Wire Diameter 1mm (0.04 in)
Spool Capacity Up to 1kg (2.2lb)

Special Features

Three Working Modes Continuous, discontinuous and program mode. In each program you can configure up to 3 steps with different dispensed wire length and speed. Up to 35 programs can be executed, cyclically programmable.
Solder Wire Perforation The solder feeder features a small blade that perforates the solder wire down to the flux core while feeding it. This perforation process allows better flux flow and outgassing and avoids solder and flux splashing when soldering.
Write Your Own Review
You're reviewing:JBC SF-210VB Automatic Solder Feeder
