CV is a microdesoldering station using compressed air for precision electronic applications. It works with the JBC exclusive heating system and the intelligent sleep & hibernation features. Using the menu you can personalize over 20 parameters to help manage the process. It incorporates a USB connector (type B) to update station software and create graphs. Complete cleaning system with an antisplash membrane to keep the work area clean. Choose from 3 cleaning methods. Use the integrated wiper to remove excess solder from the tip.CV works with the MV-A Pneumatic pump, the comfortable DS360 Microdesoldering Iron and C360 cartridges.

Qualities and Characteristics

  • Equipped with the MV-A Pneumatic pump
  • CP has a menu with more than 10 parameters to customize the control unit.
  • JBC Most Efficient Soldering System
  • Hibernation mode help to extend the life of tips
  • Antisplash membrane to keep the work area clean
  • Comfortable DS360 Micro Desoldering Iron included
  • ESD Safe

Product Contains

  • 1 CSV Control Unit
  • 1MS-A MV-A Pneumatic Desoldering Module
  • 1 DS360-A Micro Desoldering Iron
  • 5 C360002 Through hole desoldering Ø 0.8
  • 5 C360004 Through hole desoldering Ø 1.2

Technical Attributes

Vacuum 90% / 680 mmHg / 26.8 inHg
Flow Rate 15 SLPM

Selectable Parameters

Selectable Temperature 180 to 450 ºC / 360 to 840 ºF


ESD Safe
Tip to ground resistance <2 ohms

Power Supply

Peak Power 40 W - 23.5V
Ambient operating temp. 10 - 50 ºC / 50 - 120 ºF


USB-B Software PC / Firmware update
Equipotential Bonding Optional connection to EPA
Write Your Own Review
You're reviewing:JBC CS Desoldering Station with Pneumatic Pump and DS360-A Micro Desoldering Iron
Your Rating
£1,105.00 (£1,326.00 inc VAT)
JBC CS (A.K.A CDD) Desoldering Station with Pneumatic Pump and DS360-A (A.K.A DS360) Micro Desoldering Iron
